Cannondale Mavaro 1

Rahmenset

RahmenMavaro Neo, SmartForm C1 Alloy, removable 800Wh downtube battery, 1.8" headtube, internal cable routing, 135mm QR hub spacing, post mount disc brake, motor protection, integrated fender and RackLock rack - RackTime SnapIt 2.0 and child seat compatible

Fahrwerk

GabelCannondale HeadShok, 50mm travel, Quad Cage needle bearing internals, coil spring, twin chamber semi open-bath oil damping, post mount disc, 110x15mm thru-axle

DämpferNull

Bremsen

VorderradbremseTektro HD-M530 Gemini, 4-piston hydraulic disc, 203mm TR rotor (Front), 2-piston hydraulic disc, 180mm TR rotor (Rear)

Antrieb

SchalthebelEnviolo Trekking stepless controller, twist style

UmwerferNull

SchaltwerkEnviolo Continuously Variable Transmission internal gear hub

KassetteGates CDX, 22T

KetteGates CDX high performance carbon drive belt

KurbelgarniturGates Bosch E-bike, w/ 40T sprocket

TretlagerNull

Laufräder und Reifen

FelgenAlloy, double wall, 32 hole, 25mm internal width, disc-specific

Vorderradnabe(F) Shimano TC500, 15x110mm thru-axle / (R) Enviolo Trekking, continuously variable transmission, wide range internal hub

SpeichenStainless Steel, 14g

VorderreifenContinental eContact Plus w/ reflective sidewalls 27.5x2.20" 55-584 (MD), 29x2.20" 55-622 (LG, XL)

Cockpit

VorbauCannondale Urban w/ Intellimount, Alloy, 31.8mm clamp, 60mm, +30°, Acros ICR, w/ SP Connect SPC+ Stem Mount & Kiox mount

LenkergriffeErgon GC10

LenkerCannondale Urban Ergo Bar, 6061 Alloy, 25mm rise, 35° sweep, 0° rise, 680mm

SattelSelle Royal Essenza

SattelstützeParallelogram Suspension Seatpost, 31.6, 27mm travel, 350mm (MD), 400mm (LG, XL)

E-Bike

MotorBosch Performance Line CX 250W 2025

AkkuBosch PowerTube, 800Wh

Display / LenkerfernbedienungBosch Kiox 300 w/ Mini Remote & System Controller

Zubehör

PedaleCannondale Fitness Alloy
